The HDF Series Pressure Line Filter is designed for inline high-pressure applications. It features durable ductile iron housing, efficient glass fiber elements (β ≥ 200, η ≥ 99.5%), and a wide operating temperature range. Max pressure 50 MPa, flow up to 600 L/min. Suitable for mineral and synthetic oils. Contact us for other media options.
Type of Construction: Inline Mounted
Max Pressure: 50MPa
Flow Range: 600L/min
Contection: Flange
Dia: 38mm
Operation Temp: -40℃~+120℃
Filter Media: Glass Fiber
Filter head, housing material: Ductile Iron
Filtration ratio: β≥200, Filtration efficiency: η≥99.5%
Fluid Compatibility: Suitable for mineral oil, synthetic oil
Please contact our sales staff if there is any additional media you need.
